GYFXS (Corrugated Steel Tape Armored Central Loose Tube Cable)


Duct Optical Fiber Cable

The loose tube is made of high modulus plastics (PBT) and filled with a water resistant filling gel. Aramid yarn as strength member is applied longitudinally over the tube and polyethylene (PE) is extruded as sheath.

Structure:

• Loose tube: PP or other materials available
• Water blocking materials for loose tube: water blocking yarn available
• Water blocking materials for cable core: water blocking tape available
• Outer sheath: PE, aluminium tape armor, anti-termite or flame retardant materials available

Features:

• Small diameter, light weight, compact structure
• All section water blocking
• superior crush resistance
• Excellent bending performance
• Excellent transmission, mechanical and environmental performance
• Easy installation, easy maintenance
• Lifespan over 30 years

Applications:


• Duct installation
• Access network

Installation performance

• Min. bend radius: installation 20D, operation 10D
• Temperature range: storage -40～+70℃, installation -30～+70℃, operation -40～+70℃
