OM3 Multimode Fiber
A1a.2 (50/125μm)
FiberHome® 50/125μm multimode fiber is a graded-index multimode optical fiber with a 50μm core diameter and a 125μm cladding diameter. The optical fiber is comprehensively optimized for performance at the 850nn and 1300nm operating wavelengths. The fiber has the higher bandwidth and lower attenuation, which is satisfying the use at 850nn and 1300nm. FiberHome® 50/125μm multimode fiber is designed and manufactured according to the most advanced level in the world.
Characteristics:
- Designed for use at 850nm and 1300nm
- Low attenuation and high bandwidth, which overfills the transmission demand of IEEE 802.3z Gigabit Ethernet
- Good protection and excellent strip force stability
Applications:
Due to the low attenuation and high bandwidth, FiberHome® 50/125μm multimode fiber can be widely applied in local area networks (LAN), video, voice and data services. It's specially suited to Gigabit Ethernet(IEEE802.3z）using laser or light emitting diode(LED)sources. Because of the advantages of the manufacturing process (PCVD), such as extremely refined refractive index (RI) profile control, stability, etc., FiberHome® 50/125μm multimode fiber is one of the fibers that offer the highest bandwidth available in the market.
FiberHome® 50/125μm multimode fiber is applicable in all cable types including ribbon cable, loose tube stranded cable, slotted core cable, unitube cable and tight-buffer cable. FiberHome® 50/125μm multimode fibers are compatible with fibers manufactured with other processes.
Norms
- FiberHome® 50/125μm multimode fiber complies with or exceeds IEC60793-2-10 A1a optical fiber specification.
- FiberHome tightens many parameters of fiber products so as to offer more conveniences to customers.
